Talley 930734 1" Low Weatherby Vanguard Scope Mounts -Black Anodized

• High-Grade Lightweight Aircraft Aluminum
• Fully CNC Machined
• Rigid construction ensures zero will be held through thousands of rounds
• American Made, Lightweight Alloy Scope Mounts
• Made in the USA

Talley 930734   1" Low Weatherby Vanguard Scope Mounts -Black Anodized

The one-piece construction of the Talley Lightweight Alloy Scope Mount is unique. The rigid design has no joint between the scope and the gun. The Talley Lightweight unitized design eliminates the possibility of an 'out of alignment' interface or 'loose connection' between the ring and base of traditional two-piece designs. Ultimately this provides more strength and durability than rival steel rings and bases but doing it with a lighter overall weight. By extruding the billet alloy and then precision CNC machining the mount to its final design, Talley provides you with the strongest, lightest mount system on the market.

Made in America, these Weatherby Vanguard Scope Mounts made by Talley Manufacturing offer a unique and simplified one-piece scope ring and base solution for Weatherby Vanguard rifles. This simplified mounting system eliminates the possibility of an out of alignment interface or loose connection between the ring and base of traditional two-piece designs.  Ultimately this provides more strength and durability than rival steel rings and bases, but with a lighter overall weight. Fully CNC machined from lightweight aircraft-grade aluminum to the industries tightest tolerances, this rigid scope mounting platform requires no lapping and is ready to go out of the box.

• American Made, Lightweight Alloy Scope Mounts



• Fully CNC Machined



• High-Grade Lightweight Aircraft Aluminum



• Integrated Scope Ring and Base Design



• Lapping Not Required



• Designed to fit Weatherby Vanguard rifles.



• Scope Tube Diameter: 1-inch



• Ring Height: Low



• Rear Height: .521"



• Front Height: .400"



• Available for Main Tubes: 1" / 30mm



• Weight: 2.2oz/2.5oz



• Front hole spacing: .860 inches (21.84mm)



• Rear hole spacing: .600 inches (15.24mm)



• Sold in pairs (2 per pack).



• Includes mounting screws and wrench. (6-48 Screws / T-15)

1) The height is measured from the top of the action/ receiver to the bottom of the scope tube at the respective mounting location

2) Hole spacing measured center to center.
